500-312 BACnet (IP & MSTP) Receiver LoRa

SKU 500-312
by Enless
Availability:
Available
Request a quote
Original price €411,95 - Original price €411,95
Original price
€411,95
€411,95 - €411,95
Current price €411,95

Applications of the LoRa BACnet receiver

The LoRa Enless BACnet receiver allows you to receive data from 50 Enless sensors simultaneously. This BACnet gateway enables integrators to easily retrieve data from Enless LoRa sensors to a controller / a BMS. The BACnet LoRa receiver natively decodes data frames from Enless sensors and converts them into BACnet objects. It’s important to note that the BACnet Enless receiver is not a LoRaWAN gateway and is only compatible with Enless sensors.

Pairing Enless LoRa transmitters with the BACnet receiver is straightforward and can be done through the receiver’s configuration server. You can also use the configuration server to verify the Received Signal Strength Indication (RSSI) between the LoRa sensors and the receiver.

In terms of radio performance, the open-field communication range between a transmitter and the BACnet Enless gateway is over 4km. Within a building, the range may be reduced by obstacles, but Enless proprietary LoRa communication is designed for monitoring very large buildings or industrial sites. In case of a weak radio signal, you have the option to use signal repeaters can be used to extend coverage.

Recommended Antenna

The receiver is delivered without an antenna. For optimal performance, it is recommended to use a long-range antenna (ref: ANT REN SMA LR 868 – 1000-008).

The receiver is delivered without a DIN rail mounting kit. For optimal performance, it is recommended to use a DIN rail support.

Technical Specifications

Enclosure and IP rating ABS IP 60
Dimensions (lx w x h) 118 x 79 x 43mm
Mounting Wall / Collar / Din Rail (option)
Radio antenna SMA connector (provided it without antenna)
Interfaces  IP BACnet in UDP
MSTP BACnet
MSTP BACnet with BBMD
IP BACnet with UDP and MSTP BACnet
Configurable via embedded IP server
RX working temperature -20/ +55C
Power Supply Main 7,5 to 24 V DC or 12 V power supply
Radio frequency
Protocol
868 MHz bidirectional
LoRA
Options
Din Rail code (DIN RAIL 1000-005)
12 V power supply (code POWER 1000-002)
Long range antenna with 5 meter cable (ANT-REN-SMA-LR 868MHz)
10 meters extension cable (RAL-REN-10M SMA)
LED's 5 LED's and 1 external power LED
Certification CE
Ordering code RX BACNET 500-312

Do you have a question about this product?

Documentation & Downloads for BACnet Receiver LoRA style=
