UG63-868M
£211.00 GBP
SKU UG63-868M
Specifications
| Hardware System | CPU | 528 MHz, ARM Cortex-A7 |
| Memory | 256 MB DDR4 RAM | |
| Flash | 4 GB eMMC | |
| LoRaWAN | Antenna | 2 × Internal Antennas |
| Channel | 8 (Half/Full-duplex) | |
| Frequency Band | CN470/IN865/EU868/RU864/US915/AU915/KR920/AS923-1&2&3&4 | |
| Sensitivity | -140dBm Sensitivity @292bps | |
| Output Power | 27dBm Max | |
| Protocol | V1.0 Class A/Class B/Class C and V1.0.2 Class A/Class B/Class C | |
| LBT | Support | |
| Ethernet Interface | Port | 1 × RJ45 (PoE PD supported) |
| Physical Layer | 10/100 Base-T (IEEE 802.3) | |
| Data Rate | 10/100 Mbps (Auto-Sensing) | |
| Interface | Auto MDI/MDIX | |
| Mode | Full or Half Duplex (Auto-Sensing) | |
| Others | Reset Button | 1 × RST |
| Console Port | 1 × Type-C | |
| LED Indicators | 1 × SYS, 1 × LoRa | |
| Built-in | Watchdog, RTC, Timer | |
| Software | Network Protocols | PPPoE, SNMP v1/v2c/v3, TCP, UDP, DHCP, DDNS, HTTP, HTTPS, DNS, ARP, SNTP, Telnet, SSH, MQTT, etc. |
| VPN Tunnel | OpenVPN/IPsec/PPTP/L2TP/GRE/DMVPN | |
| Management | Web, CLI, DeviceHub, Milesight IoT Cloud, Yeastar Workplace Platform | |
| Power Supply | Power Input | 1. 1 × 802.3af standard PoE input 2. 5V by Type-C Port |
| Physical Characteristics | Ingress Protection | IP30 |
| Dimensions | Ф 115 x 21 mm (Ф 4.52 x 0.83 in) | |
| Color & Material | White, PC + ABS | |
| Installation | Desktop, Wall or Ceiling Mounting | |
| Environmental | Operating Temperature | -20°C to +50°C (-4℉ to +122℉) |
| Storage Temperature | -40°C to +85°C (-40℉ to +185℉) | |
| Ethernet Isolation | 1.5 kV RMS | |
| Relative Humidity | 0% to 95% (non-condensing) at 25°C/77℉ |
